Main technical data
Raw material: copper cathodeShell size: Ф90X25 mm
Shell pull speed:180~250mm/min
Power: 420KW
Melting temperature:1160~1200?C
Rotating Angle: 0~20°
Pull frequency: 20~80times/min
Cooling water: DM water
Cooling water temperature: ≤40?C
Cooling water flow rate: Natural cooling water 40 m3/h, DM flow rate(cooling) 12m3/h
Shell length: 23m
Voltage ranges: 90V, 120V, 150V, 180V, 300V, 340V, 380V
Holding furnace temperature:1150?C ~1180?C
Max melting capacity: 950kg/h
