Main Technical Data
Block Diameter: 2200mm
Block height: 400mm
Max. Drawing force: 55KN
Draw speed range: 0-1000m/min
Max. input tube size: Φ29×1.5mm
Typical product: Φ9.52X0.5mm
Min. finished tube size: Φ4.76×0.35mm
Max. coil weight: 1000kg
Basket size: Φ3050×1400mm
Draw material: Copper and its alloy
Feed in material status: Casted or extrusion coil or straight tube
Process lubricates: Mineral oil
Circulate material holder seat: 7PCS（exclude basket）
Max. moving speed of basket: 19m/min
Total motor power: 470KW
Equipment weight: 83T
Compressed air consumption: 0.8m³/min
The final product quality, dimension tolerance as well as surface quality should meet ACR copper tube standard.
Power voltage and frequency 380V, 50Hz
Power voltage alteration range: +10%V/-5%V
