Specifications
https://youtu.be/KHdF6txAzXg
https://youtu.be/rfe9WjV_Bik
Type: YLB-50T
Nominal drawing force(t): 50
Effective drawing length (m): 6/8/10/12
Material size(mm): width≤170,thickness3～30
Drawing speed (m/min): 1～10
Return speed (m/min): 10～48
ID of the cylinder (mm): 220
Diameter of the piston rod (min): 125
Oil pressure from the hydraulic station (MPa): 21
Power supply: Three-phase four-wire system,380V/50HZ
Capacity (kW): 75/75/88/90
Weight of the equipment(t): 20/23/27/32
