Specifications:
Type: YLB-80T
Nominal drawing force(t): 80
Effective drawing length (m): 6/8/10/12
Material size(mm): width≤260, thickness3～30
Drawing speed (m/min): 1～10
Return speed (m/min): 10～48
ID of the cylinder (mm): 250
Diameter of the piston rod (min): 125
Oil pressure from the hydraulic station (MPa): 21
Power supply: Three-phase four-wire system, 380V/50HZ
Capacity (kW): 75/75/88/90
Weight of the equipment(t): 23/27/32/75
Equipment Size (m): length 30/32/34/36, width 4.5, height 2.2
