Main technique parameter
Inverter control: double inverter control
Inlet dia: Φ2.5—Φ3.5mm
Outlet dia: Φ0.4---Φ1.6mm
Max.Die No: 17
Max.line Speed: 1800m/min
Body structure : Ironed cast
Drawing capstan: Tungsten plasma capstan
Slip ratio of m/c: 20%
Capstan Dia.(max): 250 mm
Fix speed capstan dia: 250 mm
Transmission type: by gear
Take-up bobbin size: 500/630 mm
Take-up type: shaftless type
Lubrication type: full immersion
Break: disc break
Dimension: 10000×2500×3200
Weight: 5500kg
